Small Carbon Canister - 5/8 outlet, horizontal asm, w/ heat shield

Part NamePart Number Carbon
Volume
Fuel Tank Capacity
(trailerable boats)
Fuel Tank Capacity
(non-trailerable boats)
Barb Size
#1      #2
System InterfaceMounting
Orientation
Length
Inches
Width
Inches
Height
Inches
Single Pack
QTY 1
Standard
Pack QTY 6
Small Carbon Canister999CC45HSH1 500ccmax 80 gal max 160 gal5/8" 5/8" Venting/RefuelingHorizontal 8.25in5.38in3.88in $--$--





  • The 999CC45HSH1 Canister is for use in trailerable boats with fuel tanks up to 80gal in size (160gal for non-trailerable).
  • The vent ports are designed for use with standard 5/8” marine vent hose and 1/2" stainless steel hose clamps.
  • Fully assembled with brackets in Horizontal orientation. (Mounting hardware not provided)


  • EPA and CARB certified
  • 2 year warranty
  • 100% leak tested before shipment
  • 100% flow tested before shipment
  • Rated for use in engine compartment
